| Nazwa | Wartość |
|---|---|
| Napięcie | 24 V |
| Moc | 2.0 kW |
| Opis | AMP2601 |
| Obr. na min | 2,200/min |
| Rotacja | ⇔ |
| S1 | - |
| S2 | 30 min |
| S3 | 45 %ED |
| Waga | 20 kg |
| Flansza | Shaft-both end |
| Ochrona termiczna | No |
| Wentylowanie | No |
| Zastosowanie | Traction |
| Uwagi | Insulated ground,Traction |
| Pos. | Spare part P/N |
|---|---|
| 1 | 15.131.596 Drive end bracket
|
| 2 | 16.908.288 Bearing
|
| 4 | 16.908.415 Armature
|
| 5 | 16.906.672 Bearing
|
| 6 | 16.908.290 Gasket
|
| 8 | 16.908.416 Stator
|
| 9 | 16.908.285 Connection plate
|
| 10 | 16.908.418 Brush holder
|
| 11 | 16.908.417 Set of brushes
|
| 13 | 16.908.419 Rear end bracket
|
| 15 | 16.908.096 Protecting cover
|
| Nazwa | Numer oryginalny | |
|---|---|---|
| ATLET | 100751 | |
| LETRIKA (ISKRA) | 11.212.771 | |
| LETRIKA (ISKRA) | AMP2601 |
| Dostawca | Dostępność |
|---|---|
| JKE |
