| Nazwa | Wartość |
|---|---|
| Napięcie | 24 V |
| Moc | 1.5 kW |
| Opis | AMK2623 |
| Obr. na min | 2,800/min |
| Rotacja | ⇔ |
| S1 | - |
| S2 | 60 min |
| S3 | - |
| Waga | 14.8 kg |
| Flansza | Shaft-both end |
| Ochrona termiczna | No |
| Wentylowanie | Yes |
| Zastosowanie | Traction |
| Uwagi | Insulated ground,Traction,Ventilation |
| Pos. | Spare part P/N |
|---|---|
| 1 | 15.133.967 Drive end bracket
|
| 2 | 16.906.382 Bearing
|
| 3 | 16.915.591 Central cover
|
| 4 | 16.907.314 Armature
|
| 5 | 16.908.956 Bearing
|
| 6 | 16.908.290 Gasket
|
| 7 | 16.907.315 Screw
|
| 8 | 16.907.316 Stator
|
| 10 | 16.908.957 Brush holder
|
| 11 | 16.908.958 Set of brushes
|
| 13 | 15.133.966 Rear end bracket
|
| 14 | 15.421.058 Fan
|
| 15 | 16.915.590 Protecting cover
|
| Nazwa | Numer oryginalny | |
|---|---|---|
| LETRIKA (ISKRA) | 11.216.521 | |
| LETRIKA (ISKRA) | AMK2623 | |
| TEKNO | 2469 |
| Dostawca | Dostępność |
|---|---|
| JKE |
