| Nazwa | Wartość |
|---|---|
| Napięcie | 24 |
| Moc | 4 |
| Liczba zębów | 10 |
| Rotacja | p |
| Liczba otworów | 3 |
| Liczba otworów gwintowanych | 0 |
| Uwagi | GR |
| Wymiar A | |
| Wymiar B |
| Pos. | Spare part P/N |
|---|---|
| 1 | 16.283.303 Drive end bracket
|
| 2 | 15.120.243 Bearing
|
| 4 | 16.915.872 Switch
|
| 6 | 16.902.835 Drive assembly
|
| 7 | 16.908.335 Lever
|
| 8 | 16.904.832 Reduction gear
|
| 9 | 16.908.993 Armature
|
| 10 | 16.908.340 Bearing
|
| 11 | 16.908.341 Fixing parts set
|
| 12 | 16.280.958 Stator
|
| 13 | 16.908.994 Brush holder
|
| 14 | 16.908.995 Set of brushes
|
| 15 | 16.285.783 Rear end bracket
|
| Nazwa | Numer oryginalny | |
|---|---|---|
| BOSCH | 0001231026 | |
| BOSCH | 0001231027 | |
| BOSCH | 0001263019 | |
| BOSCH | 0001263020 | |
| CARGO | 114196 | |
| CASE | 2852405 | |
| CASE | 2852478 | |
| FIAT | 84377568 | |
| HCP | CBS1536 | |
| IVECO | 500389863 | |
| IVECO | 504036695 | |
| IVECO | 504385577 | |
| IVECO | 5801577136 | |
| LESTER | 19727 | |
| LESTER | 19796 | |
| LETRIKA (ISKRA) | 11.132.094 | |
| LETRIKA (ISKRA) | AZF4295 | |
| LETRIKA (ISKRA) | IS1341 | |
| MARELLI | 63522630 | |
| MARELLI | MSN2118 |
